DPAM-3 catalog

Technical Specifications

• Auxiliary power
• 20 Amp. AC
• 230V ±20% , 50 Hz
• AC Input Current
• Resolution
• For Voltage: 0.1V
• For Current: 0.001A
• For Phase Angle: 0.1 Degree
• 600 V AC
• AC Input voltage
• Display
• Parameters
• 2.0 - 200V
• Voltage(V) - VR,VY&VB
• Current(A) - IR,IY&IB
• Phase Angle- Between any
• combination of V-V,V-I & I-I
• of any Phase
• Measurement
• Volt. & Amp. - True RMS Measurement
• Phase Angle Zero Crossing Based
• ANGLE BETWEEN PHASES
• Voltage - Voltage :
• YV - YV = 0
• YV - RV = 240
• YV - BV = 120
• BV - BV = 0
• BV - RV = 120
• BV - YV = 240
• RV - RV = 0
• RV - YV = 120
• RV - BV = 240
• Current - Current :
• RA - RA = 0
• RA - YA = 120
• RA - BA = 240
• YA - YA = 0
• YA - RA = 240
• YA - BA = 120
• BA - BA = 0
• BA - RA = 120
• BA - YA = 240
• Voltage - Current :
• RV - RA = 0
• RV - YA = 120
• RV - BA = 240
• YV - RA = 240
• YV - YA = 0
• YV - BA = 120
• BV - RA = 120
• BV - YA = 240
• BV - BA = 0
• Current - Voltage :
• RA - RV = 0
• RA - YV = 120
• RA - BV = 240
• YA - YV = 0
• YA - RV = 240
• YA - BV = 120
• BA - BV = 0
• BA - RV = 120
• BA - YV = 240
• Developed and Manufactured by :
• UMA ELECTRONICS ENTERPRISES
• Office-
• A-404,Vaishali Nagar,
• Near Nursery Circle,
• Jaipur , India.
• Pin-302021
• Tel: 0141-4017564
• E-mail: info@umaelectronics.com
• http://www.umaelectronics.com
• Factory-
• H1-54,Phase-1,Road 2D,
• RIICO Industrial Area,
• Bindayaka,Jaipur
• India.
• Pin-302012
• 1- Automatic Turns Ratio Meter/Flash (ATRI-3F)
• 2- Three Phase Power Analyzer (DPATT-3Bi)
• 3- Double Voltage Double Frequency (DVDF-1)
• Other Related Products
• Manual
• RM YM BM RL YL BL
• R Y B N
• Voltage I/P
• Current I/P Current O/P
• Connect Auxiliary Supply for powering the meter from the side.
• Terminal Connection
